32 43 49 55 65 inch High quality high brightness 2000 nits outdoor standalone digital signage advertising player

Interactive kiosks have long proven their value when it comes to self-service applications indoors, but they’re increasingly dominating the outdoor space as well.

Model： RF-ATS024
Operating System： Windows,Android
Installation： Wall Mounted/Bracket Mounted/Floor Standing/Ceiling Mounted
After-sales Service： 1 Year

Parameters

Model： RF-ATS024
Operating System： Windows,Android
Installation： Wall Mounted/Bracket Mounted/Floor Standing/Ceiling Mounted
After-sales Service： 1 Year

Product Detail

Features	Structure	Waterproof, dustproof, sunscreen, anti-corrosion, explosion-proof, anti-ultraviolet, anti-theft, anti-biological, Antifungal, exquisite appearance, customizable
	Display	High Definition, High Brightness, Intelligent Sensitivity, Full angle of view
	Electronic control	Lightning Protection, Leakage Protection, Intelligent Timing and Intelligent Temperature Control System
	Additional parts	Supporting remote monitoring, touch interaction, smart bank card/QR code/ID card recognition, Intelligent printing
structure	Case	1.5mm galvanized sheet, sprayed with special powder for outdoor use, with protective capacity of more than 7 years. Open door design waterproof structure, stick outdoor rubber strip seal, meet IP55 protection level
	dimension	2200850150mm(HWT)
	Display area	1209680mm(HW)
	Glass	Using 6mm high permeability toughened glass
Display	Size	32 43 49 55 65”
	Ratio	16：9
	Resolution	1920*1080
	Brightness	1500-2500 nits
	View angle	178° H / 178° V
	Brightness adjust	auto
	backlight	LED
	LED panel	Optional
Touch	10 points touch	optional
Light box	None	optional
PC Configuration	CPU	A20 Dual Core
	RAM	1GB
	ROM	8GB
	WIFI	Optional
	Playing S/W	Supporting Internet Program Publishing, Local Program Renewal, Single-machine Mode Playing
Electricity control	Switch power	Industrial grade
	Water proof speaker	Waterproof 10W Horn with High Quality
	Thunder proof	Grade three
	Leakage proof	Yes
	timer	Customized switch can be set up by day, week and month
Heat radiation	Intelligent Direct Ventilation Heat Dissipation and Heating System	Intelligent heat dissipation system, unique design of air duct and motherboard, automatic regulation of wind speed and volume
		Intelligent temperature sensing system, high temperature automatic shutdown display
		Low temperature self-starting heating module
Other parts	Camera	None,optional
Internet	Ethernet, optional wireless peripheral extension, optional 3G/4G module
Working conditions	Working temp.		-30℃~+50℃
	Working humididty		5%~95%
	Working voltage		AC 220V/50Hz
	Max.power consumption		380 W
A/V output	Audio		Supports HDMI HD video output, left and right channel output, built-in 2*10W high quality audio
	Video		Support LVDS format video output
Multimedia	Video format		WMV、AVI、FLV、RM、RMVB、MPEG、TS、MP4、VOD、MOV、MKV、MP3、AAC etc.
	Photo format		JPEG、PNG、GIG、BMP etc.
	File format		TXT、PPT、WORD、EXCEL etc.
Info post system	Optional		RTC real-time clock, timing boot, U disk update playlist, U disk network upgrade, remote control
Application scenes	Park/Gym/Bus station/Metro/Railway station/Shopping mall/Plazza/Transportation/Street scenic area/Media business circle etc.
