Coffee Table

Iteractive table with 10-point touch for simultaneous operation by multiple people. Applicable to game halls, Museums, cemeteries, banks,and other similar venues.

Model： RF-CT010
Operating System： Windows,Android
Installation： Floor Type
After-sales Service： 1 Year

Parameters

Model： RF-CT010
Operating System： Windows,Android
Installation： Floor Type
After-sales Service： 1 Year

Product Detail

1.Key Specifications/Special Features

Specification
Panel size	43″, 49″ ,55″
Maximum resolution	1920*1080
Display color	16.7M
Pixel Pitch(mm)	0.264(H)×0.264(V)
Brightness (nits)	450lm
Contrast	4000
Visual angle	178°/178°
Response time	5ms
Horizontal frequency	50-70KHZ
Vertical frequency	56-75KHZ
Life(hrs)	more than 60,000(hrs)
Touch Panel
Specification	IR 10 POINTS touches
Positioning accuracy	±1mms
Transmittance	more than 95%
Hardness	7H
Click manner	10 points
Response time	less than 10ms
Output Resolution	4096X4096
Glass	tempered glass 4 mm
Life time	Single point of more than 60 million
Video
Color system	PAL/NTSC/SECAM
Compatible input/DVI	480P,576P,720P,1080I,1080P
3D Comb filter	Yes
Video reduction noise	Yes
OSD display( screen menu display)
Menu language	Chinese/English( multiple language option required)
Computer optional(Windows system)
Main chipset	H61
CPU	Intel core i5
Memory	1.8G
Hard Disk	SATA II 5400 500GB
Operation system	Windows 10
Interface	VGA1, USB2, RJ45*1
Power
Power supply	AC100V~240V,50/60Hz
Maximum power consumption	less than 220W
Standby power consumption	less than 1W
Temperature
Working temperature	0℃~50℃
Storage temperature	-10℃~60℃
Working humidity	20%~80%
Storage humidity	5%~95%
Appearance
Body dimension(Lx W x H)mm	Customrized
Panel color/appearance	White, black, customized
Panel material	SPCC/Aluminum/Customized
Installation	Touch Table
Certificate	CE/FCC/3C/RoHS
Accessories	Manual, warranty card, remote controller,power cable,etc.
