Mirror touch screen | Touch panel | Mirror capacitive touch screen, (non conductive) diamond grade nano coated glass |
| Size | 800*600MM |
| diamond grade nano coated glass parameters | The reflectivity is 65%, and the transmittance is 35%. The surface hardness is 6H, alkali proof and acid proof (2 years), coating layer is external. It can be plated with AF to prevent fingerprint, and the effect is better. |
| Responding time | <5MS |
| Max.resolution | 4096*4096 |
| Max.touch points | 10 |
| Applicable OS | Windows7\Vista\XP\2003\2000\98\CE\Linux |
| Working temperature | -20℃~55℃ |
21.5 inch high brightness LCD display | Display size | 21.5” |
| Display ratio | 16:9 |
| Best resulotion | 1920*1080 |
| Viewing angle | 170°/170° |
| High brightness | 450cd/m² |
| High contrast ratio | 5000:1/60Hz |
| Lifespan | 5000hrs |
Android PC configuration | CPU | RK3288, Super strong quad core Cortex-A17 1.8GHz |
| GPU | ARM Mali-T746 |
| RAM | 2GB |
| Storage | 16GB |
| Ethernet | 100M LAN ( RJ45) |
| WIFI | 802.11b/g/n(Built-in WIFI antenna) |
| Bluetooth | Bluetooth communication 4 / call 2.3 |
| Speaker | 2*3w |
Housing | Aviation grade aluminum alloy + sheet metal baking paint shell |
Dimension(mm) | 800*600*33 |
Power consumption | Power input | AC100V ~240V,2A MAX ,50/60Hz |
| Power | < 39.5W |
| Standby | <1w |
others | Water-proof | IP65 |
| Installation base | SUS304 corrosion resistant stainless steel |
| Mounting screws | SUS304 corrosion resistant stainless steel |
Main functions | Can be touched,display on mirror |
| Water-proof,mist-proof,built-in secure voltage for working |
| Intelligent display, can connect to WiFi Internet, Bluetooth file transfer, watch video, live broadcast, play games. |
| Support pre-installed smart home (furniture) APP control platform, including smart doorbell, POS card swipe, lighting / bathroom water temperature control |
| Voice weather broadcast, news headlines and real-time road conditions are earlier known. |
Process scope | Max.mirror size | 2.4m*1.8m |
| Min.mirror size | 400*400mm |
| Chamfer R=60/40/20 right angle R=90 |
Customizable items(non-standard product functions) | Glass size(mm) | 1000*630,800*600,1270*370 |
| Glass thickness(mm) | 3/4/5 |
| Display area | Center display, middle and lower display, right bottom display, left bottom display. |
| Dispaly size | 32″,23.6″,21.5,18.5″,15.6″,13.3″ |
| Camera | 1080P,1300MP,500MP,300MP,200MP,720P |
| Induction mode | Panoramic 360 degrees, distance sensor, temperature induction |
| Starting up interface | Can customize static or dynamic according to client’s appointed LOGO |
| Bluetooth music | Transmit mobile phone music to the mirror through Bluetooth. |
| Software applications | software applications: makeup software, weight measurement, temperature detection, speech recognition, skin detection,second generation ID card identification, information release, home equipment control etc. |
| Light belt | Frosted lamp belt, mirror lamp belt, double color temperature light source, RGB light source, monochromatic light source |
| Clock display color | Red, green, blue, white, multi combination display |
| Memory capacity | 8G,16G,32G |
Materials | Mirror frame | Fillet section, right angle sheet metal |
| Surface treatment | Anti fingerprint treatment, semi chemical toughening, hardness 8H |
| Colors | Black, silver, gold |
| Structure | Profile, sheet metal, plastic |
| Installation method | Wall-mounted,embedded installation |
measurement | Standard sizes | 1000*630mm | 800*600mm |
